Diesel Boiler Fuel Consumption Per Hour

At present, the common condensing oil series boilers mainly include light diesel boilers, methanol boilers, alcohol-based fuel boilers, kerosene boilers, and oil-burning boilers. The boilers of these boilers mainly include SZS condensing boilers and WNS horizontal quick-install boilers. Of course, there are individual ZG type oil-fired power station boilers that use oil-fired boilers to generate electricity. Due to the particularity of the oil boiler type, the combustion efficiency is generally above 95%, plus the high calorific value of the oil, so in the calculation of the fuel consumption of the oil boiler, it is easy to draw a Customer satisfied results.

1. Calculation of oil consumption of high-efficiency oil-fired boiler
(1) Fuel consumption per hour of operating fuel steam boiler = hourly gas production of fuel steam boiler × (heat of fuel steam-heat of feed water) / low heating value of fuel × thermal efficiency of boiler
(2) Fuel oil hot water boiler runs for 1 hour. Fuel consumption = weight of water (Kg) × specific heat capacity of water × temperature difference (temperature difference between inlet and outlet water)/heat value of fuel oil × boiler thermal efficiency

The above two are more specific methods, but in fact, we can use the unified calculation formula of boiler fuel consumption to roughly estimate. After the parameters of the boiler are really determined, the engineer of the boiler manufacturer can accurately calculate it.
General calculation formula of oil consumption per hour for oil-fired boilers: 3600*heat power/heat value of fuel/heat efficiency of boiler

The thermal efficiency of a 1 ton oil-fired boiler is 0.7MW, and its combustion calorific value is 42.42Mj/kg. The general efficiency of ZOZEN oil-fired boiler can reach 90%. Then the following editor will use the 1 ton diesel boiler as an example. The fuel consumption = 3600s*0.7MW/42.42Mj/kg/90%=66kg.

Of course, this is only a rough calculation; you can also bring it into the above formula according to your actual situation. In order to ensure the minimum fuel consumption of oil-fired boilers, in addition to selecting better quality diesel, it is to choose a furnace with high thermal efficiency. ZOZEN oil-fired boiler is a furnace with extremely high thermal efficiency. It is one of the implementation sub-projects of the World Bank’s GEF high-efficiency environmental protection boiler project. It also has an internationally renowned burner to join. Sufficient Best-selling fuel oil boiler model: https://www.dieselboiler.com/category/products
