2 Pass Fire Tube Boiler: Reliable Steam Solutions for Industrial Applications

A 2 pass fire tube boiler is a widely used type of industrial boiler, recognized for its simplicity, compact structure, and reliable heat transfer. In this design, hot flue gases generated by fuel combustion pass through two sets of tubes before leaving the chimney, transferring heat to the surrounding water to generate steam. The “two-pass” configuration enhances the boiler’s thermal efficiency compared with a single-pass fire tube boiler, as more heat is absorbed from the flue gases before they exit the system. This makes 2 pass fire tube boilers particularly suitable for industries requiring consistent and stable steam output.

Industries such as packaging, food processing, textile production, and paper manufacturing frequently depend on 2 pass fire tube boilers to maintain continuous operations. Steam produced by these boilers is used for heating, sterilization, drying, and other industrial processes. The stable steam pressure and temperature control offered by a 2 pass fire tube boiler can improve product quality, increase production efficiency, and reduce energy waste. ZOZEN BOILER has leveraged decades of industrial boiler experience to provide highly reliable 2 pass fire tube boilers, ensuring that clients can meet production targets while optimizing operational costs.

WNS Gas-Fired Two-Pass Steam Boiler by ZOZEN BOILER

The boiler is equipped with imported low-NOx burners, which allow for stable combustion, low emissions, and precise fuel control. This enables WNS boilers to comply with international environmental regulations, with NOx emissions typically maintained below 30 mg/Nm³. The furnace shell employs a full-wave corrugated design, increasing heat transfer surface area while allowing for expansion and contraction under high-temperature operation. ZOZEN’s proprietary threaded smoke tubes further enhance thermal transfer, ensuring uniform and efficient steam generation.

The WNS series 2 pass fire tube boiler also integrates energy-saving components such as economizers and condensers at the flue gas exit. These devices recover residual heat from flue gases, which improves thermal efficiency and reduces fuel consumption. The combination of two-pass tube design, high-efficiency burners, and heat recovery devices allows the WNS boiler to achieve overall thermal efficiency above 98%, significantly lowering operating costs and reducing environmental impact.

Advanced automation systems are another key feature of ZOZEN’s WNS series. PLC-based intelligent control continuously monitors water level, steam pressure, fuel supply, and air intake, adjusting parameters automatically to maintain stable operation under varying loads. This allows unmanned operation, reduces labor costs, and minimizes human error. Industrial facilities benefit from this system, especially when continuous steam supply is critical for production quality.

Case Study: Steam Supply for Carton Manufacturing

In the carton and paperboard industry, maintaining a stable temperature throughout the production process is essential to ensure the quality of finished products. During corrugation, printing, and lamination, insufficient or uneven steam can lead to defective boards and production losses. A reliable 2 pass fire tube boiler ensures uniform heating and consistent moisture control, critical for achieving optimal production results.

ZOZEN BOILER has extensive experience providing WNS series boilers to packaging enterprises worldwide. Recently, a packaging company partnered with ZOZEN for a WNS series condensing gas-fired boiler system to support multiple paperboard production lines. The client required high-efficiency, continuous steam supply with low emissions to maintain product quality while adhering to environmental standards.

The WNS boiler delivered by ZOZEN featured:

Advanced Combustion Technology: Imported low-NOx burners guarantee stable combustion and reduced nitrogen oxide emissions.

Optimized Heat Transfer Surface: The full-wave furnace shell and threaded smoke tubes maximize heat absorption from flue gases.

Energy Recovery Devices: Economizers and condensers recover residual flue gas heat, increasing thermal efficiency above 98%.

Automated Intelligent Control: PLC-based system enables unattended operation, real-time adjustments of fuel and air supply, and precise steam pressure management.

Environmentally Friendly Design: Utilizes clean fuel natural gas and low-NOx technology to minimize environmental impact.

As a result, the packaging company achieved stable steam output for its paperboard lines, ensuring consistent production quality, reduced energy consumption, and compliance with environmental standards. The WNS series 2 pass fire tube boiler also helped the client reduce labor requirements and improve operational efficiency.

Expanded Applications and Benefits

Beyond the packaging industry, ZOZEN 2 pass fire tube boilers are widely applied in food processing, chemical, textile, and pharmaceutical industries. In these sectors, the boiler provides steam for sterilization, drying, cooking, and heating processes. The compact design, high thermal efficiency, and automated control system of ZOZEN’s WNS series enable these industries to maintain stable operations while reducing operating costs.

The robust construction of the 2 pass fire tube boiler ensures long-term reliability. Corrugated furnace shells withstand thermal stress, threaded smoke tubes provide extended service life, and energy-saving components maximize efficiency. Additionally, the system is designed for easy maintenance, with accessible combustion chambers and tube bundles that simplify routine inspection and cleaning.

ZOZEN’s commitment to after-sales service further enhances the value of its 2 pass fire tube boilers. Experienced engineers provide installation guidance, start-up assistance, and operational training to ensure clients can operate boilers safely and efficiently. Long-term service agreements and rapid spare parts supply minimize downtime and protect the client’s production continuity.

Summary of ZOZEN 2 Pass Fire Tube Boiler Advantages

ZOZEN BOILER’s WNS series 2 pass fire tube boilers offer numerous advantages for industrial clients:

High thermal efficiency exceeding 98%, reducing fuel costs and environmental impact.

Stable and uniform steam output suitable for a wide range of industrial processes.

Low emissions thanks to low-NOx burners and clean fuel compatibility.

Intelligent automation system for unmanned operation and real-time process adjustments.

Durable construction with corrugated furnace shells and threaded smoke tubes.

Integrated energy recovery devices for enhanced heat utilization.

Comprehensive after-sales support including installation, start-up, and maintenance guidance.

For industries seeking reliable, efficient, and environmentally friendly steam solutions, ZOZEN’s 2 pass fire tube boiler provides a proven solution that meets production demands while optimizing operational costs. By integrating advanced design, high-quality construction, and expert support, ZOZEN ensures clients achieve stable steam supply, operational efficiency, and compliance with environmental regulations.

With over a decade of experience supplying industrial boilers worldwide, ZOZEN continues to refine its 2 pass fire tube boiler design, ensuring optimal performance and long-term reliability for diverse industrial applications.
